CAVITY FILTER

home > 제품 소개 > CAVITY FILTER
  • 100 ~ 530MHz BPF
  • 4850 ~ 5500MHz BPF
  • 5100 ~ 5160MHz BPF
  • 7900 ~ 8400MHz BPF

Specification

Items Specification
Pass band Frequency 100 ~ 530MHz
Insertion Loss 1.0dB Max
Ripple 1.0dB Max
Return Loss 15dB Min
Rejection
  • 40dB Min @ 20~88MHz
  • 50dB Min @ 1550~1600MHz
Connector N
Impedance 50 Ω
Operating Temperature -30℃ ~ +80℃
Dimension (WxDxH) 100.0 X 65.0 X 28.0 mm
Power Handling 100W Max
Data sheet
Items Specification
Pass band Frequency 4850 ~ 5500MHz
Insertion Loss 0.6dB Max
Ripple 0.3dB Max
Return Loss 18dB Min
Attenuation
  • 30dB Min @ 5700MHz
  • 30dB Min @ 4650MHz
  • 60dB Min @ 6000MHz
  • 60dB Min @ 4350MHz
Spurious / Harmonics 60dB Min @ 9500~17000MHz
Connector SMA
Impedance 50 Ω
Operating Temperature -30℃ ~ +80℃
Dimension (WxDxH) 54.0 X 121.0 X 18.0 mm
IP Code IP67
Data sheet
Items Specification
Pass band Frequency 5100 ~ 5160MHz
Insertion Loss 1.0dB Max
Ripple 0.3dB Max
Return Loss 18dB Min
Attenuation
  • 35dB Min @ 5220MHz
  • 35dB Min @ 5050MHz
  • 60dB Min @ 5660~18000MHz
  • 60dB Min @ 30~4600MHz
Spurious / Harmonics 60dB Min @ 9500~17000MHz
Connector SMA
Impedance 50 Ω
Operating Temperature -30℃ ~ +80℃
Dimension (WxDxH) 54.0 X 121.0 X 18.0 mm
IP Code IP67
Data sheet
Items Specification
Pass band Frequency 7900 ~ 8400MHz
Insertion Loss 1.0dB Max
Ripple 0.5dB Max
Return Loss 18dB Min
Impedance 50 Ω
Operating Temperature -35℃ ~ +75℃
Dimension (WxDxH) 22.0 X 46.5 X 29.0 mm
Data sheet
